Differential Pressure
| Cartridge replacement: |
2.0 bar @ 25 °C |
| Max. allowable: |
6.0 bar @ 25 °C (epoxy glued)
8.0 bar @ 25 °C (crimped)
15 bar @ 25 °C (welded) |
Max Working Temperature
120 °C (epoxy glued)
300 °C (crimped)
360 °C (welded)
Construction Materials
Filte-r media / hardware:
304 SS (H, E version)
316 SS (G, H, E version)
Gaskets:
Buna-n
EPDM
Viton
Silicone
FEP
PTFE (only DOE)
KlingerSil (only DOE)
Dimensions
| External diameter: |
2.4” (60 mm) Crimped
2.5” (63 mm) Epoxy glued
2.7” (68 mm) Welded |
| Internal diameter: |
1.0” (26 mm)
1.4” (36 mm) (only cod. 9 |
| Length: |
10”, 20”, 30”, 40” |
Filtering Area
Pleated: 0.20 m2 x 10”
Cylindrical: 0.05 m2 x 10”
Flow-rate / Delta-P data:
| Filtration (μm) |
Cylindrical |
Pleated |
Air |
|
1 cP |
25 cP |
70 cP |
1 cP |
25 cP |
70 cP |
0.018 cP |
| 10 |
1.60 |
0.50 |
0.30 |
1.80 |
0.60 |
0.40 |
90 |
| 25 |
2.00 |
1.10 |
0.85 |
2.50 |
1.50 |
1.25 |
130 |
| 45 |
2.50 |
1.40 |
1.20 |
2.50 |
1.60 |
1.40 |
160 |
| 75 |
2.50 |
1.80 |
1.60 |
2.50 |
1.80 |
1.60 |
160 |
| 100 |
2.50 |
1.80 |
1.60 |
3.00 |
1.80 |
1.60 |
180 |
| 150 |
3.00 |
2.10 |
1.90 |
3.00 |
1.80 |
1.60 |
200 |
| ≥ 250 |
3.00 |
2.10 |
1.90 |
3.00 |
2.00 |
1.80 |
280 |
Liquid flow-rate (m3/h) - Air flow-rate (Nm3/h @ 7 barg) - Clean Delta-P 0.1 bar
For gas different than air: DP = 0.1 x gas viscosity (cP) / 0.018 cP (air)
Flow-rate valid for clean water and air, reduce the flow-rate according to the application.
Gaskets temperature limitation:
| EPDM |
120 °C |
Viton |
230 °C |
PTFE |
250 °C |
FEP |
250 °C |
| Buna-n |
120 °C |
Silicone |
230 °C |
KlingerSil |
360 °C |
|
|
Features:
|
WMGP |
WMPH |
WMEP |
WMGC |
WMEC |
| 304 SS |
|
X |
X |
X |
X |
| 316 SS |
X |
X |
X |
X |
X |
| Food Grade |
X |
X |
|
|
|
| External spring |
X |
X |
|
|
|
