Gaskets and O-Rings
FDA approved Ethylene Propylene, PTFE encapsulated, Silicone or Nitrile.
Maximum Differential Pressure
| Normal flow direction at: |
| 20°C (68°F): |
6.0bar (87psi) |
| 80°C (176°F): |
4.0bar (58psi) |
| 100°C (212°F): |
3.0bar (43psi) |
| 120°C (248°F): |
2.0bar (29psi) |
Sterilisation
In situ steam 30 x 25 minute cycles at 125°C (257°F).
Effective Filtration Area
| Absolute Microbial Rating |
Effective Filtration Area (each 254mm (10") module) |
| 0.2μm |
0.5m2 (5.38ft2) |
Applications
Hydrofil™ Plus cartridges are suitable for the sub-micronic filtration of a wide range of process liquids, in applications where the characteristics of a naturally hydrophilic membrane are required.
- Biopharmaceuticals
For the sterilisation of biological fluids, cell culture media, sera and blood fractionations.
- Fermentation
For providing sterile feed stock for the production of antibiotics and enzymes.
- API's
- LVP's
For final filtration of Total Nutritional Fluids, dextrose, amino acids and saline solutions.
- Beverages
- Pure water supply
Clean Water Flow Rates
