Gaskets and O-Rings
FDA approved Ethylene Propylene, PTFE encapsulated, Silicone or Nitrile.
Maximum Differential Pressure
| Normal flow direction at: |
| 20°C (68°F): |
6.0bar (87psi) |
| 80°C (176°F): |
4.0bar (58psi) |
| 100°C (212°F): |
3.0bar (43psi) |
| 120°C (248°F): |
2.0bar (29psi) |
Extractables
Minimum total extractables. Please refer to the HydrofilTM HT Validation Guide.
Effective Filtration Area
| Absolute Microbial Rating |
Effective Filtration Area (each 254mm (10") module) |
| 0.1, 0.2 and 0.45μm |
0.69m2 (7.4ft2) |
Applications
- Biopharmaceuticals
For the sub-micronic filtration of ingredients, intermediates, make-up waters and final products, including sterilisation, clarification and bioburden reduction.
- Electronics and semiconductors
For the sub-micronic filtration of process water and chemicals, including solvents, developers and photoresists. Applications typically include central water plant treatment and critical ‘wet bench’ point of use filtration.
- Fine chemicals
- Beverages
- Pure water supply
Clean Water Flow Rates
